Customization: OEM or ODM
After-sales Service: Online Support / Video Technical Support / Engineer Support
Warranty: 12 Months
Intelligent Integrated Control Panel
– Electric Digital Constant Temperature Control, Motor Frequency Conversion Speed Regulation, Easy Temperature and Speed Adjustment.
Conveyor Belt Independent Frequency Conversion
– Automatically adjusts speed according to different requirements of fabric to prevent deformation and elongation of fabric (material).
Imported High – Quality Motors
– Equipped with imported premium brand motors and reducers that have been in use for many years, achieving stable operation, long service life, and durability.
Frequency Converter
– The winding speed can be independently controlled.
Pneumatic Pressure Device
– Pneumatic pressure system ensures good pressure balance during high-speed operation; front – mounted silicone shaft provides better pressure transfer effect.
Teflon Double – Layer Roller
– Composite steel roller, even heat distribution, precise temperature control; utilizing galvanization technology, strong hardness, wear -resistant and non – stick, excellent transfer performance.
Carpet Separation – No need for cooling Shutdown
– Automatic carpet separation, no need for cooling shutdown, preventing damage from prolonged contact between carpet and roller; manual separation lever available for use when power is off.
Imported DuPont Blanket
– Thick and densely woven surface, sturdy and tight, extra – thick pile blanket, long- lasting shaping, durable and resistant to abrasion and high temperature.
Automatic Blanket Advancement and Retraction
– Consistent Tension on blanket, protecting it and increasing its lifespan.
Emergency Stop Switch
– In case of emergency, pressing the emergency stop will immediately shut down the machine.
Simple & Reliable Process: From digital design to finished product, the heat transfer process is streamlined for consistent, high-yield results using environmentally friendly materials.
Cost-Effective Production: Perfect for both small batches and large-scale runs. Eliminate plate-making fees and enjoy fast production speeds, making sample creation and custom orders highly economical.
Heat Transfer Process
Create or upload a high-resolution design.
Print the pattern onto specialty heat transfer paper.
Use a HOLDWIN heat press machine to transfer the design onto the product with precise temperature and pressure control.
Achieve a ready-to-sell, professional-grade finished product.
– Lycra materials-cycling
– Polyamide – Swim & Surfwear
– 100% polyester(stretch)-cycling, running, ice hockey wear
– Sports and functional textiles
Curtain, Blind, Cushion, Table Cover, Towel Cleaner, etc.
Flags, Banners, Felts, Gaming tables, Home Textiles
Ceramics, Metal plates, Skis, Snowboards, Mug, Cup
| Drum Diameter | 420mm |
| Transfer Width | 1700mm / 1900mm |
| Voltage | 380V |
| Power | 28KW |
| Temperature Range | 0-400°C |
| Time Range | 0-999 seconds |
| Main Machine Dimensions | 1100 * 1260 * 2580 (Three air-inflated shafts are provided with automatic oiling device and no foot pedal) |
